PW-DIP-0718D

Model: PW-DIP-0718D
Product Name: LTE700+GSM900 & DCS+3G Diplexer
VIEW SPECIFICATIONS

Electrical
Frequency Range (MHz)Port 1: 698-960 MHzPort 2: 1710 - 2170 MHz
Insertion Loss (dB)<0.3
Return Loss (dB)≤-20
Isolation (dB)≥50 dB
Impedance (Ω)50
Input Power (W)300 (avg.)
Intermodulation-155 dBc @ 2 x 43 dBm
DC/AISGDC Path thru each port to Ant. Rated at 3A Max.
Lighting Protection3KA;10/350us pulse
Environment
Operating Temperature (°C)-40 to +60
Storage Temperature Range-35 to +75
Relative Humidity5% - 95%
ApplicationIP66
Mechanical
ConnectorsDIN-F
Weight (Kg)1.3 Kg (Single unit) 2.7Kg (Double unit)
Dimension (mm)(L*W*H)178*100*50 / (272*110*65.max)
Packaging1 pc in box
